exMHR Overview
The exMHR is a cutting edge, ground-based, multi-mission radar for Counter-UAS, Very Short-Range Air Defense (VSHORAD), Counter Rocket, Artillery and Mortar (C-RAM), Fire Control, and Hemispheric Surveillance operational missions.
This pulse-Doppler, software-defined, S-band radar platform incorporates GaN amplifiers and advanced antenna topology, enabling fire-control tracking accuracy, as well as unprecedented clutter handling and multipath mitigation.
The exMHR is a best-of-breed radar with exceptional situational awareness and survivability during combat that offers superior SWaP-C and On-The-Move operation capabilities.
Operational Missions
Key Features
Active Electronically Scanned Array (AESA) antenna- Extremely high doppler resolution that provides fast, accurate threat detection and classification
- Wide range of threat velocities
- Coexistence capability
- Multipath reduction and clutter handling through advanced antenna topology
- Electronic Counter Countermeasures (ECCM) capabilities
- Cyber Certification (Risk Management Framework) Ready
- Integrated with IFF
Main Advantages
Extended fire-control tracking accuracy, multipath and clutter handling through advanced antenna topology- At the heart of mobile GBAD systems
- Complete Dynamic Air Situational Picture (ASP) while mounted on a tactical vehicle or vessel
- Superior performance against low signature targets
- Multi-Mission – “one radar does it all”
- MOSA – Modular Open System Architecture, easily integrated with all kinds of Hard and Soft kill systems
- Software-defined, automated operation through advanced signal processing and algorithms
- Handles hundreds of targets through Track While Search (TWS) and Revisit modes
- Enhanced fast volume scan coverage, full Hemispheric (360°) search & track with four radars
- In-depth 4D analysis of Doppler and other target features
- SWaP-C superiority, unprecedented affordability
Radar Specifications
Configurable, Software Defined Radar
| Parameters | Details |
|---|---|
| Spatial Coverage | Single radar: 90˚Az, 90˚ El ; 4x overlapping radars: 360˚ Az |
| Interfaces | Ethernet, I/O Discrete |
| Interface Protocols | ASTERIX, Customer-tailored |
| Input Power | 28 VDC |
| Power Consumption | 2,500 W average |
| Dimensions | Height: 90 cm, Width: 120 cm, Depth: 30 cm |
| Weight | 150 kg |
| Operation Temperature | -40°C to +55°C |
| Cooling Method | Passive (fans are added for harsh environments) |
Maximum Detection Ranges
| Threat | Detection Range |
|---|---|
| Nano UAV | 18 Km |
| Medium-Size UAV | 80 Km |
| Heavy Transport Aircraft | 200 Km |
| Fighter | 110 Km |
| Fighter – Low RCS | 60 Km |
| Utility Helicopter | 80 Km |
| Light/Medium Mortar / Short Range Rocket | 18 Km |
| Heavy Mortar | 20 Km |
| Direct- Attack Rocket / Missile | 24 Km |
| Vehicles & Medium-Size Vessel | 80 Km |
| Large Vessel | 130 Km |
